Showing 1–16 of 21 results
-
item value Applicable Industries Construction works , Energy & Mining Showroom Location Egypt, United States, Germany, Viet Nam, Philippines, Brazil, Saudi Arabia, Indonesia, Pakistan, India, Russia, Thailand, Argentina, South Korea, Chile, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Uzbekistan, Malaysia, Australia Video outgoing-inspection Provided Machinery Test Report Provided Marketing Type Hot Product 2023 Warranty of…
-
Item Parameter Operating Weight 48000kg Rated Power 210kW/2000rpm Engine Model QSB6.7 Max. output torque 150kN.m Rotary speed 27rpm Max pulling force of main winch 185kN Max pulling speed of main winch 35m/min Max drilling diameter 800mm Max drilling depth 20m Dimensions 13060×2960×3125mm
-
Item Parameter Operating Weight 48000kg Rated Power 210kW/2000rpm Engine Model QSB6.7 Max. output torque 150kN.m Rotary speed 27rpm Max pulling force of main winch 185kN Max pulling speed of main winch 35m/min Max drilling diameter 800mm Max drilling depth 20m Dimensions 13060×2960×3125mm
-
Main performances Unit Parameters Overall height mm 18,432 Operating weight t 46 Max. pile diameter mm 1,500 Max. pile depth(friction Kelly/inter-locking Kelly) m 56/44 Max. output torque kN.m 150 Speed of rotation rpm 6.5~40 Crowd force kN 160 Line pull kN 160 Stroke mm 4,250 Main winch Line pull(1st layer) kN 160 Rope diameter mm…
-
Description Unit Parameter value Engine Manufacturers Dongfeng Cummins China III Model QSB5.9-C210 Rated Power kW /(r/min) 154 / 2200 China II Model 6BTAA5.9-C205 Rated Power kW /(r/min) 153/ 2200 Thrust-Pull Type Pinion and rack drive Max thrust-pull force kN 360/360 Max thrust-pull speed m/min 22 Rotation Type Four motor Torque N·m 12000 Max spindle speed…
-
item value Applicable Industries Construction works , Energy & Mining Showroom Location Egypt, United States, Germany, Viet Nam, Philippines, Brazil, Saudi Arabia, Indonesia, Pakistan, India, Russia, Thailand, Argentina, South Korea, Chile, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Uzbekistan, Malaysia, Australia Video outgoing-inspection Provided Machinery Test Report Provided Marketing Type Hot Product 2023 Warranty of…
-
item value Applicable Industries Construction works , Energy & Mining Showroom Location None Video outgoing-inspection Provided Machinery Test Report Provided Marketing Type Hot Product 2023 Warranty of core components 1 Year Core Components PLC, Engine, Bearing, Gearbox, Motor, Pump Condition New Place of Origin China Shanghai Dimension(L*W*H) 2610*4000mm Weight 10500kg Warranty 1 Year Product name Tunnel…
-
Item Parameter Operating Weight 22000kg Rated Power 92kW/2200rpm Engine Model YCF36125 Max. output torque 65kN.m Rotary speed 35rpm Max pulling force of main winch 95kN Max pulling speed of main winch 85m/min Max drilling diameter 1200mm Max drilling depth 27m Dimensions 7360*2260*3000mm
-
Main parameter Units YCR40 Chasis Rated power/speed kW/rpm 44/2200 Track width(margin) mm 2260 Track shoe width mm 450 Rotary Drive Max.output torque kN.m 40 Rotary speed rpm 0~45 Max.pull-down piston push kN 70 Max.pull-down piston pull kN 60 Max.pull-down piston strike mm 1500 Main Winch Max.pulling force kN 50 Max.pulling speed m/min 50 Wire rope…
-
Item Parameter Operating Weight 22000kg Rated Power 92kW/2200rpm Engine Model YCF36125 Max. output torque 65kN.m Rotary speed 35rpm Max pulling force of main winch 95kN Max pulling speed of main winch 85m/min Max drilling diameter 1200mm Max drilling depth 27m Dimensions 7360*2260*3000mm
-
Model Unit XR160E Engine Rated power kW 133 Power unit Max. output torque kN.m 150 Rotate speed r/min 6~28 Max. drilling diameter mm 800 Max. drilling depth m 20 Max. extraction force kN 400 Main winch Max. winch speed m/min 75 Diameter of steel rope mm 28 Vice winch Max. elevation force kN 50 Max….
-
Model SR360 Line Pull 360kN Stroke 9000/18000mm Engine 6WG1 Emission Regulation EUR Ⅲ Engine Power 300/1800kW/rpm Max. Line Speed 65m/min Rope Diameter 36mm Operating Weight 131T Overall Height 27105mm Transport Height 3575mm Transport Width 3530mm Max. Pile Depth 100/65m Max. Pile Diameter 2500/2200mm Rotary Drive 340KN Max. Output Torque 365kN·m Speed of Rotation 5~23rpm
-
Model SR265-C10 SR285R-C10 SR335R-C10 Max. Pile Diameter 2200mm 2300mm 2500/2000mm Max. Pile Depth 73/58m 94/61m 100/65m Rotary Drive Rated Output Torque 265kN·m 285kN·m 335kN·m Rated Speed 5~25rpm 285rpm 5~27rpm Crowd System Crowd Force 230kN 260kN 275kN Line Pull 275kN 335kN 335kN Stroke 5000mm 6000mm 6000mm Main Winch Lifting Capacity 275kN 335kN 335kN Rope Diameter 32mm…
-
item value Applicable Industries Construction works , Energy & Mining Showroom Location Egypt, United States, Germany, Viet Nam, Philippines, Brazil, Saudi Arabia, Indonesia, Pakistan, India, Russia, Thailand, Argentina, South Korea, Chile, Colombia, Algeria, Sri Lanka, Romania, Bangladesh, South Africa, Uzbekistan, Malaysia, Australia Video outgoing-inspection Provided Machinery Test Report Provided Marketing Type Hot Product 2023 Warranty of…
-
Model HDD150A HDD180 HDD280 HDD320 HDD320A Engine rated power 100KW 97KW 160KW 140KW/160KW 160KW Push and pull Cylinder Motor Motor Cylinder Motor Maximum drag/feed force 160/100KN 180/180KN 280/280KN 320/320KN 320/320KN Maximum torque of power head 5000N.n 6000N.n 10000N.n 12000N.n 12000N.n Power head speed 0-180r/min 0-140r/min 0-120r/min 0-140r/min 0-140r/min Moving speed of power head 30m/min 20m/min…
-
SR150C Unit Parameters Max.Drilling Dia. mm 1500 Max.Drilling Depth m 55 largest torque kN.m 150 Speed of rotary drive totation rpm 7-14 Max.push kN 150 Max.pull kN 160 Crowd stroke mm 4250 Mast sideward . (+/-)5 Mast forward . 5 Main winch pull(1st layer) kN 160 Main winch wire rope dia. mm 28 Max.main winch…
