Earthmoving Machinery Mini Digger Sy20c Crawler Excavator
Feel free contact with our sale!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
|
Item
|
Unit
|
SY20C
|
|
|
Operating weight
|
kg
|
1750
|
|
|
Bucket capacity
|
m3
|
0.04
|
|
|
Engine
|
Engine model
|
–
|
3TNV70
|
|
Output power
|
kW/rpm
|
10.3/2200
|
|
|
Max. torque
|
N.m
|
48.2-52.4
|
|
|
Displacement
|
L
|
0.854
|
|
|
Main performance
|
Travel speed(H/L)
|
km/h
|
3.7/2.1
|
|
Grade ability
|
%
|
70
|
|
|
Rotary speed
|
r/min
|
10
|
|
|
Ground pressure
|
kPa
|
29.1
|
|
|
Bucket digging force
|
kN
|
15.2
|
|
|
Arm digging force
|
kN
|
9.2
|
|
|
Oil Capacity
|
Fuel tank capacity
|
L
|
23
|
|
Hydraulic tank capacity
|
L
|
21
|
|
|
Engine oil capacity
|
L
|
2
|
|
|
Appearance size
|
Overall length(Transport)
|
mm
|
3575
|
|
Overall width(Transport/Working)
|
mm
|
980/1350
|
|
|
Overall height(Transport)
|
mm
|
2420
|
|
|
Top width
|
mm
|
980
|
|
|
Bulldozer height
|
mm
|
270
|
|
|
Standard track shoe width
|
mm
|
230
|
|
|
Track gauge(Transport/Working)
|
mm
|
750/1120
|
|
|
Minimum ground clearance
|
mm
|
180
|
|
|
Tail swing radius
|
mm
|
920
|
|
|
Track ground length
|
mm
|
1225
|
|
|
Track length
|
mm
|
1585
|
|
|
Working scope
|
Max. digging height
|
mm
|
3665
|
|
Max. dumping height
|
mm
|
2635
|
|
|
Max. digging depth
|
mm
|
2360
|
|
|
Max. vertical wall digging depth
|
mm
|
2215
|
|
|
Max. digging reach
|
mm
|
3900
|
|
|
Min. swing radius
|
mm
|
1655
|
|
|
Max. height at minimum swing radius
|
mm
|
2745
|
|
