Economical Type LONKING 3.5 Ton Fd35te Mini Diesel Forklift With Solid Tire Hot Sale
Feel free contact with our sale!
- Satisfaction Guaranteed
- No Hassle Refunds
- Secure Payments
|
Item
|
Unit
|
FD35TE
|
||
|
Main Specification
|
Power type
|
–
|
Diesel
|
|
|
Rated capacity
|
kg
|
3500
|
||
|
Load center
|
mm
|
500
|
||
|
Dimensions
|
STD Max height (with backrest)
|
mm
|
4210
|
|
|
STD Max lifting height
|
mm
|
3000
|
||
|
Overhead guard height
|
mm
|
2130
|
||
|
Overall length (with fork)
|
mm
|
3900
|
||
|
Wheelbase
|
mm
|
1760
|
||
|
Front overhang
|
mm
|
496
|
||
|
Rear overhang
|
mm
|
570
|
||
|
Min.ground clearance (Frame/Mast)
|
mm
|
160/130
|
||
|
Overall width
|
mm
|
1240
|
||
|
Adjusting range of fork (outside)
|
mm
|
255-1095
|
||
|
STD Fork size (L5*W*T)
|
mm
|
1070×122×50
|
||
|
Front wheel tread
|
mm
|
1000
|
||
|
Rear wheel tread
|
mm
|
980
|
||
|
Min.turning radius
|
mm
|
2420
|
||
|
Min aisle width for pallet 1000×1200,crossways
|
mm
|
4260
|
||
|
Min aisle width for pallet 800×1200,lengthways
|
mm
|
4390
|
||
|
Tires
|
Wheels number, front/rear (X=driven wheels)
|
–
|
X=2/2
|
|
|
Tires type
|
–
|
Pneumatic
|
||
|
Tires size, front
|
–
|
28×9-15-14PR
|
||
|
Tires size, rear
|
–
|
6.50-10-10PR
|
||
|
Other Details
|
Max.traveling speed, loaded/unloaded
|
km/h
|
18.5/20
|
|
|
STD operating weight (with oil & water)
|
kg
|
4650
|
||
|
Axles loading,front/rear (loaded)
|
kg
|
7265/865
|
||
|
Axles loading,front/rear (unloaded)
|
kg
|
1760/2870
|
||
|
Fuel tank capacity
|
L
|
60
|
||
|
Battery votage/capacity
|
V/Ah
|
12/80
|
||
